Heat Exchanger and Condenser

Heat Exchanger and Condenser Manufacturer in Ahmedabad, India

Dyke Engineering Services is a leading Heat Exchanger and Condenser Manufacturer in Ahmedabad, India, offering a comprehensive range of high-performance solutions for efficient industrial heat transfer applications. Designed and fabricated in full compliance with TEMA (Tubular Exchanger Manufacturers Association) and ASME Section VIII, Division 1 standards, our Heat Exchangers and Condensers are known for their precision, durability, and operational excellence.

Each unit is meticulously engineered to deliver maximum thermal efficiency, energy conservation, and process safety across diverse industries including Chemicals, Pharmaceuticals, Petrochemicals, Food Processing, and Power Plants. Available in both GMP and Non-GMP configurations, our systems are designed to operate under a wide range of temperature and pressure conditions — from deep vacuum to high-pressure service environments.

Backed by years of manufacturing expertise and innovation, Dyke Engineering Services provides custom-built Heat Exchangers and Condensers in various materials such as Stainless Steel, Carbon Steel, Titanium, Inconel, Alloy 20, and other special alloys. Every design ensures long-term reliability, corrosion resistance, and consistent performance under demanding industrial operations.

  • Technical Specifications
  • Key Features
  • Applications

Technical Specifications

Parameter Specification
Capacity Range 1 m² to 500 m²
Pressure Range Vacuum to 20 kg/cm²g
Design Standard ASME Section VIII Div. 1 & TEMA Standards
Type GMP & Non-GMP Configurations
Material of Construction (MOC) SS316, SS316L, SS304L, Hastelloy C22/C276, Inconel, Alloy 20, 904L, Super Duplex
Heat Transfer Type Shell & Tube / Double Pipe / Coil Type
Orientation Vertical or Horizontal as per requirement
Surface Finish Mirror / Matt / Electro-Polished
Applications Temperature Up to 300°C (customizable)

Key Features

  • Designed and fabricated in accordance with TEMA & ASME Section VIII standards.
  • Available in GMP and Non-GMP models for industrial and cleanroom applications.
  • High heat transfer efficiency ensuring maximum energy recovery.
  • Customizable design – Shell & Tube, Double Pipe, or Coil Type.
  • Corrosion-resistant materials for long-lasting performance.
  • Low maintenance design with easy inspection and cleaning.
  • Suitable for both vacuum and high-pressure operations.
  • Engineered for safe condensation, vaporization, and cooling processes.

Applications

  • Pharmaceutical and Biotech Plants
  • Chemical and Petrochemical Industries
  • Food, Beverage & Dairy Processing Units
  • Agrochemical and Fertilizer Manufacturing
  • Resin, Paint & Pigment Production Units
  • Power and Energy Plants
